AMD Radeon RX 7800 XTvsNVIDIA GeForce RTX 4060 Spec Comparison

The AMD Radeon RX 7800 XT and the NVIDIA GeForce RTX 4060 are desktop graphics cards released in 2023. They differ significantly in price, raw compute capability, video memory, and power requirements.

Report a problem

Intro

What is the problem?

eBay prices refresh hourly — check the listing before you buy. We may earn a commission.

Report a problem

Best for

What is the problem?
Which products? Tick all that apply, or none if you are not sure.

Biggest differences

  • Memory bandwidth

    AMD Radeon RX 7800 XT leads

    2.29×

    higher is better

    • AMD Radeon RX 7800 XT624 GB/s
    • NVIDIA GeForce RTX 4060272 GB/s

  • Board power

    NVIDIA GeForce RTX 4060 leads

    2.29×

    lower is better

    • AMD Radeon RX 7800 XT263 W
    • NVIDIA GeForce RTX 4060115 W

  • Video memory

    AMD Radeon RX 7800 XT leads

    2×

    higher is better

    • AMD Radeon RX 7800 XT16 GB
    • NVIDIA GeForce RTX 40608 GB

  • Memory bus width

    AMD Radeon RX 7800 XT leads

    2×

    higher is better

    • AMD Radeon RX 7800 XT256 bit
    • NVIDIA GeForce RTX 4060128 bit

Where each one wins

  • AMD Radeon RX 7800 XT

    • Shader cores
    • FP32 compute
    • Video memory
    • Memory bus width
    • Memory bandwidth
    • Memory speed
    • Last-level cache
    • PCIe lanes
    • DisplayPort version

  • NVIDIA GeForce RTX 4060

    • Launch price
    • Boost clock
    • Base clock
    • Board power
    • Recommended PSU
    • HDMI outputs
    • Slot width

What both have

  • Memory typeGddr6
  • Power connectors8-pin
  • PCIe version4.0
  • HDMI version2.1a
  • DisplayPort outputs3 ports
  • Max displays4 displays

Every spec

Red marks the better value in each row.

SpecAMD Radeon RX 7800 XTNVIDIA GeForce RTX 4060
Overview

Report a problem

Overview specs

What is the problem?
Which specs? Tick all that apply, or none if you are not sure.
Which products? Tick all that apply, or none if you are not sure.
Release date2023-092023-06
Launch price499 USD299 USD
Graphics chip

Report a problem

Graphics chip specs

What is the problem?
Which specs? Tick all that apply, or none if you are not sure.
Which products? Tick all that apply, or none if you are not sure.
ArchitectureRdna 3Ada lovelace
Shader cores3,840 cores3,072 cores
Boost clock2,430 MHz2,460 MHz
Base clock1,295 MHz1,830 MHz
FP32 compute37.3 TFLOPS15 TFLOPS
Memory

Report a problem

Memory specs

What is the problem?
Which specs? Tick all that apply, or none if you are not sure.
Which products? Tick all that apply, or none if you are not sure.
Video memory16 GB8 GB
Memory typeGddr6Gddr6
Memory bus width256 bit128 bit
Memory bandwidth624 GB/s272 GB/s
Memory speed19.5 Gbps17 Gbps
Last-level cache64 MB24 MB
Power

Report a problem

Power specs

What is the problem?
Which specs? Tick all that apply, or none if you are not sure.
Which products? Tick all that apply, or none if you are not sure.
Board power263 W115 W
Recommended PSU700 W550 W
Power connectors8-pin8-pin1
Interface

Report a problem

Interface specs

What is the problem?
Which specs? Tick all that apply, or none if you are not sure.
Which products? Tick all that apply, or none if you are not sure.
PCIe version4.04.0
PCIe lanes16 lanes8 lanes
Display outputs

Report a problem

Display outputs specs

What is the problem?
Which specs? Tick all that apply, or none if you are not sure.
Which products? Tick all that apply, or none if you are not sure.
HDMI version2.1a22.1a
DisplayPort version2.131.4a
HDMI outputs1 ports2 ports
DisplayPort outputs3 ports3 ports
Max displays4 displays4 displays
Video engine

Report a problem

Video engine specs

What is the problem?
Which specs? Tick all that apply, or none if you are not sure.
Which products? Tick all that apply, or none if you are not sure.
Hardware encodeH.264, HEVC, AV1AV14
Video encodersNot published1 encoders
Size

Report a problem

Size specs

What is the problem?
Which specs? Tick all that apply, or none if you are not sure.
Which products? Tick all that apply, or none if you are not sure.
Card length267 mmNot published
Card heightNot publishedNot published
Slot width2.5 slots2 slots
Notes on 4 values — test conditions and caveats
  1. 1NVIDIA GeForce RTX 4060, Power connectors: Reference card takes one 8-pin (adapter in the box); some partner models use a 6-pin instead.
  2. 2AMD Radeon RX 7800 XT, HDMI version: AMD's spec page lists HDMI 2.1; its own press release and Notebookcheck state HDMI 2.1a.
  3. 3AMD Radeon RX 7800 XT, DisplayPort version: Notebookcheck lists the DisplayPort 2.1 link rate as UHBR13.5; AMD notes DP 2.1 support depends on AIB designs.
  4. 4NVIDIA GeForce RTX 4060, Hardware encode: Checked pages only confirm AV1 encode; H.264/HEVC encode is not stated.

Performance and Memory

The Radeon RX 7800 XT delivers much higher raw compute capability at 37.3 TFLOPS and features 16 GB of video memory with a 256-bit memory bus width. This configuration provides a massive memory bandwidth advantage of 624 GB/s and a 64 MB last-level cache.

In contrast, the GeForce RTX 4060 offers 15 TFLOPS of FP32 compute and includes 8 GB of video memory on a narrower 128-bit bus. The heavier memory load on the AMD card handles dense textures and high resolutions much more effectively during long gaming sessions.

Report a problem

Performance and Memory

What is the problem?

Power and Efficiency

The GeForce RTX 4060 focuses heavily on efficiency with a board power of 115 W and requires a modest 550 W power supply. It provides a much cooler and less demanding electrical footprint for standard desktop builds.

The Radeon RX 7800 XT demands a 263 W board power and a 700 W recommended PSU. Buyers must ensure their power supply unit and case ventilation can handle the higher electrical draw before installing the card.

Report a problem

Power and Efficiency

What is the problem?

Display Outputs and Connectivity

Both cards support PCIe 4.0, but the Radeon RX 7800 XT utilizes a full 16 PCIe lanes compared to the 8 lanes on the GeForce RTX 4060. For monitors, the AMD card stands out with DisplayPort 2.1 support, though AIB designs dictate final implementation.

The NVIDIA alternative counters with two HDMI ports instead of one, while both options support a maximum of four displays simultaneously. Hardware encoding also varies, as the GeForce card explicitly confirms AV1 encode with one encoder, while the AMD card adds H.264 and HEVC support.

Report a problem

Display Outputs and Connectivity

What is the problem?

The Verdict

Buy the Radeon RX 7800 XT if you need heavy memory bandwidth and high compute performance for demanding titles at a $499 launch price. Buy the GeForce RTX 4060 if you want an efficient 115 W card with a lower power supply requirement at a $299 launch price. Reference cards for the NVIDIA option take one 8-pin connector with an adapter in the box, while some partner models use a 6-pin instead.

Report a problem

Verdict

What is the problem?

Where to buy

FAQ

What is the launch price difference between these two graphics cards?

The Radeon RX 7800 XT launched at $499, whereas the GeForce RTX 4060 launched at $299.

How much video memory does each graphics card have?

The Radeon RX 7800 XT comes with 16 GB of GDDR6 video memory, while the GeForce RTX 4060 features 8 GB of GDDR6.

What are the recommended power supply requirements?

The Radeon RX 7800 XT requires a 700 W power supply, while the GeForce RTX 4060 requires a 550 W power supply.

Do both cards support the same PCIe version?

Yes, both graphics cards operate on PCIe 4.0, though the AMD card uses 16 lanes while the NVIDIA card uses 8 lanes.
